Automatic Sulfur Burning Furnace for Accurate Sulfur Content Analysis

Sulfur analysis is important in many industries, including metallurgy, chemical processing, environmental monitoring, petroleum, coal, and materials research. Accurate sulfur content testing requires reliable combustion equipment that can provide stable temperatures, complete sample combustion, and consistent gas flow.

The RJZS-ZG-500 Automatic Sulfur Burning Furnace is a high-temperature sulfur combustion system designed for efficient and reliable sulfur analysis. It uses an intelligent automatic control system to support the combustion of solid or liquid sulfur samples under controlled high-temperature conditions.

High-Temperature Stable Combustion

The furnace features a high-temperature-resistant ceramic combustion chamber designed for long-term operation at temperatures of approximately 1200–1500°C. Its uniform thermal field helps promote complete combustion and improve the accuracy of sulfur analysis. The adjustable combustion temperature range is 800–1500°C, with a maximum operating temperature of 1550°C.

Intelligent Automatic Control

The RJZS-ZG-500 integrates PLC control with a touch-screen interface. Automatic ignition, temperature regulation, sample introduction, combustion, and exhaust operations can be managed through the control system.

With automatic temperature control and PID regulation, the system can maintain temperature accuracy of approximately ±1°C. One-button operation also helps reduce manual errors and improve testing repeatability.

Safety and Environmental Protection

Safety is an important consideration in high-temperature sulfur combustion. The furnace includes over-temperature protection, gas leakage alarms, and automatic shutdown functions in the event of a fire.

The system also incorporates an acid gas absorption and purification system for exhaust treatment. This helps control combustion emissions and supports laboratory and industrial environmental requirements.

Flexible Applications

The automatic sulfur burning furnace can be used for sulfur content analysis in iron ore, steel, mineral samples, sulfide products, petroleum, and coal. It is also suitable for environmental laboratories and research institutions conducting material composition testing.

The equipment can process sulfur samples ranging from 1 to 30 grams, with the capacity customizable according to specific requirements.

Easy Maintenance and Operation

The modular structure makes individual components easier to inspect, clean, and replace. Key parts such as the igniter, gas lines, and thermocouples are designed for convenient maintenance.

The combination of automatic control, stable combustion, gas flow monitoring, and modular maintenance makes the RJZS-ZG-500 suitable for laboratories and industrial production environments that require efficient sulfur testing.

Conclusion

The RJZS-ZG-500 Automatic Sulfur Burning Furnace provides a practical solution for high-temperature sulfur combustion and sulfur content analysis. With stable temperature control, automatic operation, safety features, exhaust purification, and flexible sample processing, it can support reliable testing across metallurgy, chemical engineering, environmental monitoring, petroleum, coal, and materials research applications.
