Earth Resistance Online Detector developed by Sunlight company does not change any design structure of the original grounding system, and adopts on-line monitoring technology such as non-contact measurement, which will not affect the grounding effect and the normal operation of facilities. There is no need for self-test and real-time detection,and The product can be installed and used as a single product, or it can be formed into a wired network system or a wireless network component system. With the support of the system, the data can be stored. Through the curve display of the accumulated data, you can intuitively see the changing trend of the ground grid and detect whether the ground grid is in health conditions or not.

Earth Resistance Online Detector (Mini Type, wired) transmission modes

Wired network system: data transmission through RS485 communication protocol, composed of main communicator (concentrator), monitoring software, power adapter, computer, etc., suitable for close distance, convenient construction wiring.

Sunlight Earth/Ground Resistance Online Detector/tester advantages(Mini Type, wired mode)

Sunlight grounding resistance online monitoring system passes various tests, such as The highest harsh level requirements stipulated by surge, static electricity, pulse group, radiation immunity, power frequency magnetic field immunity, voltage short drop, radio frequency magnetic field conduction harassment, That is  to say, Sunlight Earth/Ground Resistance Online Detector/tester (Explosion proof) can work in a stable strong interference environment.

also, the product passes the 100 KA lightning surge test. That is to say,  during the actual operation of the product, when 100 KA lightning current pass through, Sunlight Earth/Ground Resistance Online Detector/tester detector works normally.

Grounding Resistance Online Detector parameter (Mini Type, wired)

Class of protection: IP65 and WF2, can be used outdoors

Power supply: 85~265VAC/DC

Range of resistance: 0.01Ω～200Ω

Resolution ratio: 0.001Ω

Precision: ≤1Ω(Error ≤10mΩ, 20℃±5℃, 70%RH below);   ≤100Ω(Error≤±1%)

Working Environment: -40℃～85℃，Humidity ≤95%RH (no condensation）

Overflow indication: If the value is larger than 100Ω, the" — ”symbol is displayed

Alarm output: Panel alarm and indicator light triggered simultaneously; Dry contact (with 5A / 220VAC)

Communication interface: RS485 (ModBUS RTU protocol), photoelectric isolation, 1200 m /9600bps

Size of product: 169mm×142mm×150mm

Ground wire perforation dimensions: 54mm×21mm, Closed mouth type (can pass through 54mmX10mm flat steel or Ф20mm cable)

Installation: The ground wire passes through the central hole of the detector and fixed on the ground flat steel

Lead Time

15 workdays

After-sale Service(within 24hrs)

Any product quality problems occurs, our salesman and technical&product engineer will response within 24hrs

Earth/Ground Resistance Online Detector/tester Application

Suitable for tower grounding of transmission lines; Meteorological lightning protection grounding; Grounding of communication; Grounding of transformer distribution station; Grounding of railway facilities; Grounding of building warehouse; Electrical equipment grounding.
